    Dilatoflex & Kledil Bellows

mercia flexibles  have been specialists in the manufacture and supply of a wide spectrum of flexible hose assemblies and expansion joint products for four decades. Amongst our range are :

  • Stainless Steel Corrugated Hose Assemblies :
  • Stainless Steel Bellows Expansion Joints & Compensators :
    • Axial, Lateral, Angular & Universal
    • Hinged & Gimbal
    • H&V & Perimeter Heating Bellows
    • Multi-Ply Pump Bellows
    • High Temperature Flue Gas & Exhaust Expansion Joints
  • Rubber Bellows Expansion Joints :
    • Flanged DIN/PN, ANSI/ASA, British BS10, JIS
    • EPDM, Hypalon, Nitrile/NBR/Buna-N/Perbunan, Chloro-Butyl, Natural Rubber,
      SBR, Neoprene/Chloroprene, Gum Rubber
    • Flexible Pump Connectors & Hump Hoses
    • Viton or PTFE Lined Expansion Joints for Chemicals & Solvents
    • DIN4809, DVGW, Steel Mesh or Aramid Reinforced
  • Braided Fan Coil & Chilled Ceiling Hoses in EPDM or Stainless Steel
  • Air & Dirt Separators, Dosing Pots, Buffer Vessels, & Low Loss Headers
  • Braided Automotive Stainless Steel Exhaust Bellows Flexibles
  • PTFE Bellows & PTFE Hose Assemblies
  • Expansion Joints in Duplex, Monel, Inco, Hastelloy & Avesta Grades
  • Flexmaster Joint Couplings
  • Trellex & Kleber Bloc-End Hose Coupling Connectors
  • Stainless Steel & Galvanised Steel Interlock Stripwound Hose
  • Fabric Duct Expansion Joints & Gaiter Bellows
  • Food Grade Hygienic Hoses & Bellows
  • Composite Hoses for Chemical, Oil or Cryogenic Service
  • Rubber Air Spring Bellows, including :
    • Springride, Pneuride, Parker, and Norgren
    • Firestone, Goodyear, Contitech, and Torpress


Stainless Steel Hose AssembliesDilatoflex MDilatoflex NT ES High Temperature Bellows


mercia flexibles are UK & Eire agents for the Kléber Dilatoflex range of European manufactured rubber bellows couplings. The Dilatoflex range of expansion joints are available in rubber grades AR/CN, CC, GZ, YP, TE, AB, CTW, HH, & ES, plus drinking water & foodstuff approved grades DW & EPC, and include the : (click on underlined headings to download pdf file)

    * Dilatoflex K Range - Swivel Flanges - No-Flange-Pullout Design
             - Available rated upto 110 ºC - Available with Food & Drinking Water Approvals
             - 32 mm (1¼") to 300 mm (12") NB
    * Dilatoflex KP Range - High Pressure 25 BarG Rated - Swivel Flanges
             - No-Flange-Pullout Design - Available with Food & Drinking Water Approvals
             - 32 mm (1¼") to 300 mm (12") NB
    * Dilatoflex KT Range - With Integral Control/Tie Rods - Swivel Flanges
             - 32 mm (1¼") to 300 mm (12") NB

    * Dilatoflex K/F1 Range - PTFE Lined - Swivel Flanges - No-Flange-Pullout Design
             - 32 mm (1¼") to 300 mm (12") NB

    * Dilatoflex K/CTW Range - Aluminium Swivel Flanges
             - For Use On Tank Wagons & Tankers

    * Dilatoflex NT Range - Full Faced Rubber Flanges
             -
    NT1 Single Arch & NT2 Double Arch
             - Available rated upto 110 ºC - Available with Food & Drinking Water Approvals
             - 20 mm (¾") to 450 mm (18") NB

    * Dilatoflex NT/ES Range - High Temperature :16 BarG @ 140 ºC and 25 BarG @ 70 ºC
             - Steel Mesh Reinforced
             - 20 mm (¾") to 450 mm (18") NB

    * Kledil Range - Available with Stainless Steel or Carbon Steel Male Screwed Ends
             - Available rated upto 110 ºC - Available with Food & Drinking Water Approvals
             - 20 mm (¾") to 50 mm (2") NB

    *
    Dilatoflex BT Range - Swivel Flanges - Untied & Tied
             - 300 mm (12") to 1000 mm (40") NB

    * Dilatoflex N Range - Full Faced Rubber Flanges
             - 500 mm (20") to 3000 mm (120") NB

    * Dilatoflex NT/MH & NT/MB Range - Military & Defense Approved
             - NATO Stock Numbered

    * Dilatoflex M Range - Special Build - Full Faced Rubber Flanges
             - 500 mm (20") to 2600 mm (104") NB

    * Dilatoflex U & BP  Ranges
             - Rectangular & Dog Bone
    * PSC-Flex Style 99 Economy Range


Dilatoflex K RangeDilatoflex K & Kledil RangeDilatoflex NT Range


We are exporters to over 80 countries, and industries supplied include :

    • Petrochemical & Pharmaceutical
    • Food & Agriculture
    • Combustion
    • Paper & Pulp
    • Heating & Ventilation, Air Conditioning & Refrigeration
    • Construction, Iron & Steel
    • Nuclear & Power Generation
    • Water & Sewage
    • Marine, Automotive & Defence

mercia flexibles can also supply flexible rubber pump connectors from
Emflex, Stourflex, ERV, Masterflex, Jet, Elaflex, Toraflex,
Albion, AFAFlex, Stenflex & Teguflex.


Tied Stainless Steel Expansion JointDilatoflex K Grade YP BellowsHigh Temperature Exhaust Stainless Steel Expansion Joints


mercia flexibles  were previously located in Surbiton, Chessington and Leatherhead under the name mercia trading & manufacturing co. until our move to Ludlow in 1999.

mercia flexibles are also UK & Eire agents for Klematch P37 and P59
billiard, snooker, carom & pool cushions.

Braided Flexible Hose
